Gasketing & Sheet Rubber

SPIRAL WOUND GASKETS

Metallic spiral wound gasket with yellow outer ring

A spiral wound gasket is a type of gasket used to create a seal between two surfaces, typically in piping systems carrying fluids or gases under pressure. It's designed to withstand high temperatures, pressures, and varying conditions. Here's how it's constructed and why it's effective:

  1. Construction: A spiral wound gasket consists of several components:

    • A metallic winding (usually stainless steel) in a V-shaped or W-shaped profile.

    • Filler material, often graphite or PTFE (Teflon), which fills the space between the windings.

    • Inner and outer rings made of solid metal (typically carbon steel or stainless steel) that act as centers for the winding and provide additional strength and stability.

  2. Functionality: When the gasket is compressed between two flanges, the metal windings deform to fill any irregularities on the flange surfaces, while the filler material provides a seal. The inner and outer rings prevent over-compression of the windings and help maintain the gasket's shape and integrity under pressure.

  3. Benefits:

    • Versatility: Spiral wound gaskets can be used in a wide range of applications, including high-temperature and high-pressure environments.

    • Resilience: The metallic winding provides strength and resilience, while the filler material ensures a tight seal, even in conditions with varying temperatures and pressures.

    • Durability: They are durable and can withstand mechanical stress, thermal cycling, and chemical exposure better than some other types of gaskets.

  4. Applications: Spiral wound gaskets are commonly used in industries such as oil and gas, petrochemical, power generation, and chemical processing where reliable sealing is critical to prevent leaks and ensure system integrity.

Overall, spiral wound gaskets offer a combination of strength, flexibility, and reliability, making them a popular choice for sealing applications in demanding environments.

  • Large yellow and black industrial gasket against a white background

    Spiral Wound Gaskets

    - SPIRAL WOUND GASKET STYLE 913 AND 913M (TEADIT STYLE CG AND CGI) We stock 304 and 316 stainless w/ and w/ out inner rings

    - SPIRAL WOUND STYLE 913M CMP / 913M OX and 913M CMP ECHOELON HF

    - 913M CMP FLEXES are just like the regular CGI flexes but with a camprofile inner ring regular used for alky services in refineries

    - 913M OX FLEXES are just like the 913M flexes as well but made in a controlled and safe environment to insure being free from organic contaminants and fire safe.

    - The 913M CMP ECHELON HF These are monel inner ring and PTFE faces for services where we see extremely dangerous chemicals and flanges are exposed to extreme crevice corrosion

    - SPIRAL WOUND STYLE 914 non circular windings such as ovals, rectangles and squares for boilers, handholes and manholes

    - STYLE 911 AND 911M These are regular circle shaped windings w/ and without inner rings

  • Gray circular gauge with partial scale markings on a reflective surface

    Exchanger Gaskets

    - STYLE 923 JACKED GASKETS (Flat double jacketed gaskets typically used for Heat Exchangers)

    - STYLE 940 CAMPROFILE GASKETS (Great sealing under pressure and temperature fluctuations, flange rotation, stress relaxation and creep)

    - STYLE 905 METALBEST (Corrugated metal gaskets with graphite facing providing superior sealing in heat exchangers with heavy thermal cycling applications)

    METAL MATERIALS AVAILABLE
    CARBON STEEL
    304 STAINLESS
    316 STAINLESS
    321 STAINLESS
    347 STAINLESS
    MONEL
    COPPER
    INCONEL
    TITANIUM
    NICKEL 200

    FACING MATERIALS AVAILABLE
    FLEXIBLE GRAPHITE
    APX2 FLEXIBLE GRAPHITE
    MICA
    XHR
    PTFE

  • Round gasket with multiple holes, marked NA 1001, on a white background.

    Compressed Fiber Sheet

    - NA1001 Compressed sheet with aramid fibers and NBR Binder (Outstanding General service gasket material)

    - NA 1100 Compressed sheet with Carbon Fiber and NBR Binder (High temperature and pressure resistant Great for petroleum derivatives, saturated steam, solvents, gases and general chemical products)

    - NA1122 High performance steam service sheet with NBR Binder (Developed for superior thermal stability during extreme thermal cycling applications, specifically recommended for saturated and superheated steam services)

    - 1082 SAN Sanitary Service Gasket Material (Designed for drinking water system components with NSF-61)

    - NA1088 Controlled Swell Sheet (High density controlled swell with proprietary biner and reinforced with a synthetic/inorganic fiber blend Ideally used in difficult to seal applications where bolt loading or flange surface conditions are not ideal)

    - TM 1860 AND TM 1863 Extreme Heat Resistant Mica (Excels in extreme heat conditions and difficult sealing applications such as exhaust and silencer applications)

    GARLOCK SHEET
    Garlock 3000
    Garlock 3200
    Garlock 3300
    Garlock 3400
    Garlock 3760
    G3700
    G9900

    FRENZELIT
    900F SHEET

    KLINGER SHEET
    Klinger 4401
    Klinger 4300

  • White circular ring light with a plain background

    PTFE Products

    - TF1500 Virgin PTFE sheet

    - TF 1525 25% Glass Filled PTFE

    - TEALON TF1570 Restructured PTFE with Glass Spheres

    - TEALON TF1590 Restructured PTFE with Silica

    - GA LOCK GYLON 3500

    - GARLOCK GYLON 3504

    - GARLOCK GYLON 3570

    - GARLOCK GYLON 3545

  • Roll of Teadit 25 BI PTFE joint sealant tape, featuring branding and product details on a spool.

    ePTFE PRODUCTS

    - 24SH ePTFE GASKET SHEET (100% Expanded PTFE sheet)

    - 24B PTFE Joint Sealant

  • Stack of four rectangular rubber sheets in black, brown, blue, and white on a white background.

    Elastomers (Sheet Rubber)

    NEOPRENE
    NITRILE (BUNA-N)
    RED RUBBER
    FKM / VITON
    EPDM RUBBER
    SILICONE RUBBER
    GUM / NATURAL RUBBER
    NEOPRENE DIAPHRAM RUBBER
    FDA FOOD GRADE RUBBER (EPDM / WHITE BUNA)
    NSF-61 FDA APPROVED
    AFLAS
    CORK/NEOPRENE
    CC NEOPREME FOAM WITH AND WITHOUT PSA
    SILICONE SPONGE SHEETS AND EXTRUSION
    SPONGE FKM
